8.KIS40.13B2.1024 KÜBLER ENCODER

ECHANICAL

Dimension
Ø 40 mm
Shaft type
6 mm shaft, with flat surface
8 mm shaft, with flat surface
1/4 " shaft, with flat surface
Flange type
Synchro flange / Servo flange
Clamping flange
Ø 40.00 mm
Working temperature
-20 °C ... +70 °C
Protection level
IP64
Connection types
Axial cable
Radial cable
Max. rotational speed
4.500 min-1
Weight
170 g

ELECTRICAL

Scanning
optical
Resolution max.
2.500 ppr incremental
Power supply
5 V DC
5...30 V DC
10...30 V DC
Interfaces
Gegentakt
TTL / RS422
Open Collector
